TGFlash is a complete solution for ECU flash memory reading, virtual reading and reprogramming. TGFlash supports ECU identification, reading and DTC clearing. TGFlash communicates with ECU via any J2534 Passthru interface (OpenPort, Mongoose, PassThru ACTIA, Scanmatik, etc) or ENET cable.
KEY FEATURES
- Master version is purchased with at least one of the available protocols.
- Master version differs from Standard the way that it can have connected Slave versions for further coding of slave files for a number of writings and/or time expiration with protection from unauthorized reuse. Thus Master version is suited for companies and individual tuners who want to protect their files from unauthorized use.
- Slave versions and their annual renewals are purchased by Master. It has access to all protocols purchased by its Master as long as the subscription is valid. The Slave version saves ECU readouts which can be decoded only by its Master and can only use files provided by its Master. Thus, it is perfect for those who do not tune files themselves.
- Additionally, Master & Slave versions have messaging (with file attachments if needed) functionality for convenient communication.
All TGFlash protocols automatically adjust file checksums (also known as CS) and signatures on writing.
You get the software download link and activation key via email IMMEDIATELY after your payment. No USB dongles, just a license key which links to your computer during installation. You can use the license key only on one computer and only one instance of TGFlash software
And last, but not least — we do test protocols BEFORE selling them!
REQUIREMENTS
- Computer with Microsoft Windows 7, 8, 10. 32-bit or 64-bit
- J2534 Passthru interface or BMW ENET cable (depending on the protocol)
- Stable internet connection
- Adequate car battery charger
RESTRICTIONS
- You can’t run TGFlash on virtual or cloud computers (VMware, VirtualBox, etc).
- It is highly recommended to perform all Windows updates, replace/upgrade computer components BEFORE installing TGFlash, or even use a dedicated PC. If for any reason (HDD/motherboard fault, etc) hardware ID will change — we allow you to reinstall TGFlash on another computer up to 2 (two) times per year, but ONLY for Master and Standard versions, for Slave, it is not possible.
- Migration of Slave license from one Master to another is not allowed.
ACTIVATION
To apply for activation you must send us the end user email which is the login to the TGFlash personal cabinet. If you purchase a Slave license — include the Master’s email. If you purchase Slave Renewal — write the Slave’s email there. Please write the email in the field with the serial number.
The technical support is provided by the developer directly.
Copyright TGFlash.com
Bosch MD1CP002, MG1CS003: Reading, Virtual reading, Writing, Checksum corrections
Software versions supported: up to 2019–11 (inclusive) and 2020–03 (partially)
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW & MINI cars:
Engine: B46B20A, B48A20A, B48B20A, B58B30A (Series: F20, F21, F22, F23, F30, F31, F32, F34, F35, F36, F45, F46, F48, F55, F56, F57)
Engine: B46B20A, B47D20A, B48B16A, B48B20A, B57D30A, B58B30A, N63B44C, N74B66B (Series: G01, G02, G05, G07, G11, G12, G29, G30, G31, G32, G38)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …) or BMW ENET cable.
OBD Read protection after writing.
Bosch MD1CS001, MG1CS201, MG1CS024: Reading, Virtual reading, Writing, Checksum corrections
Software versions supported: up to 2019–07 (inclusive)
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW & MINI cars:
Engine: B48A20A, S63B44B (Series: F39, F45, F46, F48, F55, F56, F90)
Engine: B48B20B, B47D20B, B58B30C, N63B44D, N74B66C (Series: G01, G02, G05, G07, G11, G12, G20, G29, G30, G31, G32)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …) or BMW ENET cable.
Read protection after writing.
Bosch MEVD17.2, MEVD17.2.3, MEVD17.2.4, MEVD17.2.5, MEVD17.2.6, MEVD17.2.8, MEVD17.2.9, MEVD17.2.G, MEVD17.2.H, MEVD17.8.4: Virtual reading, Writing, Checksum corrections
Software versions supported: up to 2018–03 (inclusive)
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW & MINI cars:
Engine: B38A15, N13B16, N20B20, N26B20, N55B30, N63B44 (Series: F01, F02, F07, F10, F11, F15, F16, F20, F21, F22, F23, F25, F26, F30, F31, F32, F34, F35, F36, F39, F48, F54, F55, F56, F57, F60)
note: BMW M2 Competition S55B30 not supported
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …) or BMW ENET cable
Bosch EDC17C41, EDC17C50, EDC17C56, EDC17C76, EDC17CP09, EDC17CP45, EDC17CP49: Virtual reading, Writing, Checksum corrections
Software versions supported: up to 2018–03 (inclusive)
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW & MINI cars:
Engine: B37C15, B37D15, B47D20, B47C20, N47D20, N57D30 (Series: F01, F02, F07, F10, F11, F15, F16, F20, F21, F22, F23, F25, F26, F30, F31, F32, F34, F35, F36, F39, F48, F54, F55, F56, F57, F60)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …) or BMW ENET cable
EGS GKEB23, GKEB23TU, ZFBCC: Reading, Virtual reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW cars:
Transmission: 8HPGKE23, 8HPGKE23TU (Series: F01, F02, F10, F11, F15, F16, F20, F21, F22, F23, F25, F26, F30, F31, F32, F34, F35, F36, F45, F46, F48, F90)
Transmission: 8HPZFBCC (Series: G01, G02, G05, G07, G11, G12, G30, G31, G32, G38)
note: 8HPZFBCE not supported
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …) or BMW ENET cable
Bosch EDC16C31, EDC16CP35: Reading, Virtual reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW cars:
Engine: M47, M57, M67 (Series: E60, E65, E70, E71, E90, E91, E92, E93)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …)
Bosch MEVD17.2, MEVD17.2.2, MEVD17.2.7, MEVD17.2.9: Virtual reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW & MINI cars:
Engine: N55B30 (Series: E70, E71, E81, E82, E87, E88, E90, E91, E92, E93)
Engine: N18B16 (Series: R56, R60)
note: will be added MEVD17.2.6
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Bosch EDC17C41, EDC17C50, EDC17C06,EDC17CP02, EDC17CP09, EDC17CP45: Virtual reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW cars:
Engine: N47D20, N57D30 (Series: E60, E83, E84, E70, E71, E81, E82, E87, E88, E90, E91, E92, E93)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Siemens Continental TCU PDK: Virtual reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) via OBD
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Siemens Continental SID208: Reading, Virtual reading, Writing, Checksum corrections
Reading (Full) via OBD ⁄ Writing (Calibrations) via OBD (Unlock isn't needed)
For the following Ford vehicles:
Engine: 2.2TDCi, 3.2TDCi (Model: Ranger, Tourneo Custom, Transit, Transit Custom)
Note: if ECU was already flashed via BDM - our software may have difficulties reprogramming it
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Siemens Continental MSD85, MSD87: Reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) on Bench via J2534
For the following BMW cars:
Engine: N54B30, N63B44, N74B60 (Series: F01, F02, F03, F07, F10, F11, F12, F13)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Generic bench connection cable can be used.
Siemens Continental MSV90: Reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) on Bench via J2534
For the following BMW cars:
Engine: N52B25, N52B30 (Series: F01, F02, F10, F11, F18, F25)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Generic bench connection cable can be used.
Siemens Continental SDI6, SDI6.1, SDI7, SDI8: Reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) on Bench via J2534
For the following Porsche cars:
Engine: 3.0 V6, 3.6 V6, 4.8 V8, 4.8 V8 Turbo (Model: Cayenne 958, Panamera 970)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Generic bench connection cable can be used.
Bosch EDC17C66, EDC17CP46, EDC17CP57, EDC17CP60
Reading ⁄ Writing (Calibrations) via OBD
For the following Mercedes cars:
Engine: 180 BlueTec, 200 BlueTec, 300 BlueTec, 350 BlueTec, 200 CDI, 220 CDI, 250 CDI, 350 CDI
(Model: B (W246), C (W204), C (W205), CLS (C218), E (W212), E (W213), GL (X166), GLC (X205), GLE (C292), GLK (X204), ML (W166), SLK (R172), Sprinter (W906), V (W447), Vito (W447))
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Siemens Continental SID209: Reading, Virtual reading, Writing, Checksum corrections
HW# supported are: EB3A, GB3A
Reading ⁄ Writing (Calibrations) via OBD
For the following Ford cars:
Engine: 2.2TDCi, 3.2TDCi (Model: Endeavour, Everest, Ranger)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
Siemens Continental SID211: Reading, Virtual reading, Writing, Checksum corrections
Reading ⁄ Writing (Calibrations) via OBD
For the following Ford cars:
Engine: 2.0 TDCi EcoBlue (Model: Tourneo Custom, Transit, Transit Custom)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, ...)
EGS GKE233
Reading ⁄ Writing (Calibrations) via OBD
For the following BMW cars:
Transmission: 8HPGKE233 (Series: E84, E89, E70, E71)
You can use J2534 (Actia Passthru, Drew Technologies Mongoose, Scanmatik, Tactrix OpenPort, …)
001 BMW Fxx/Gxx Bosch MDG1 SPC5777M 7.5MB CAN/ENET
002 BMW Fxx/Gxx Bosch MDG1 AURIX TC2xx 8.0MB CAN/ENET
003 BMW Fxx Bosch MEVD17.2.X TC179x 4.0MB CAN/ENET
004 BMW Fxx Bosch EDC17 TC1797 4.0MB CAN/ENET
006 BMW Fxx/Gxx EGS 8HP 2.0MB / 2.5MB CAN/ENET
007 BMW Exx Bosch EDC16 1.0MB / 2.0MB CAN/K-Line
008 BMW Exx Bosch MEVD17 TC179x 4.0MB CAN
009 BMW Exx Bosch EDC17 TC1766 1.5MB / TC179x 4.0MB CAN
013 BMW Exx/Fxx Siemens Continental MSD85/87 TC1796 2.0MB Bench
014 BMW Fxx Siemens Continental MSV90 TC1796 2.0MB Bench
012 Ford Siemens Continental SID208 TC1797 4.0MB CAN
019 Ford Siemens Continental SID209 [EB3A/GB3A] TC1797 CAN (BETA)
020 Ford Siemens Continental SID211 TC1791 2.0MB CAN
001 BMW Fxx/Gxx Bosch MDG1 SPC5777M 7.5MB CAN/ENET
002 BMW Fxx/Gxx Bosch MDG1 AURIX TC2xx 8.0MB CAN/ENET
006 BMW Fxx/Gxx EGS 8HP 2.0MB / 2.5MB CAN/ENET
003 BMW Fxx Bosch MEVD17.2.X TC179x 4.0MB CAN/ENET
004 BMW Fxx Bosch EDC17 TC1797 4.0MB CAN/ENET
006 BMW Fxx/Gxx EGS 8HP 2.0MB / 2.5MB CAN/ENET
008 BMW Exx Bosch MEVD17 TC179x 4.0MB CAN
009 BMW Exx Bosch EDC17 TC1766 1.5MB / TC179x 4.0MB CAN
013 BMW Exx/Fxx Siemens Continental MSD85/87 TC1796 2.0MB Bench
014 BMW Fxx Siemens Continental MSV90 TC1796 2.0MB Bench
