ZENITH Z5 – The next evolution of G-SCAN scanners.
The new, state-of-the-art ZENITH Z5 scanner meets the most advanced requirements of modern diagnostics. The device is a tablet-style unit featuring a powerful octa-core processor, the Android 9 operating system, and a bright, high-resolution display.
The scanner supports dealer-level software for Hyundai and Kia, as well as all the European, Asian, and US vehicle brands typically covered by G-scan scanners—including 24V commercial vehicles.
The ZENITH Z5 is the ideal solution for auto repair shops focused on in-depth diagnostics for vehicles from around the world (Make and Model Support: Vehicle support is based on the coverage chart). It features the familiar menu structure characteristic of G-scan scanners.
High Cost-Efficiency
There is no need to pay a premium price for the device. The Zenith Z5 features state-of-the-art hardware and supports all communication protocols, yet it costs less than many European and Chinese counterparts, ensuring a quick return on investment.
Full Support
The Zenith Z5 runs on the same software as its predecessors—the G-scan 1, G-scan 2, and G-scan 3. The vehicle software and menus are identical. Additionally, the Zenith Z5 supports vehicles with older diagnostic connectors and the J2534 pass-thru protocol.
Versatility
The device is ready for immediate use. The battery provides several hours of operation and charges very quickly. The menu is controlled via a Full HD (1920 x 1200) touchscreen.
Dealer-Level Software
The diagnostic software for Hyundai and Kia is identical to the dealer-level tools used at authorized dealerships for these Korean manufacturers. All diagnostic functions are the same.
User-Friendly Interface
The scanner menu is available in Russian and mirrors that of earlier models. The interface is simple and intuitive.
Truck Support
The device supports diagnostics on 24V electrical systems. The Zenith Z5 supports Hyundai/Kia trucks (since January 2022), as well as Isuzu, Hino, Fuso, UD, MAN, Scania, and Mercedes-Benz. Support for additional brands is also planned (Heavy-Duty Vehicle Support: The Zenith Z5 supports commercial vehicles with 24V electrical systems).
Wireless Data Transmission
The device supports fast data transfer via Bluetooth and Wi-Fi. This allows for software updates without disconnecting from the vehicle, report printing, and the downloading of files for reprogramming and bypassing manufacturer Security Gateways (SGW).
Reliability and Compact Design
The device is built to last and features a compact housing. It is lightweight and comes with a protective rubber casing to shield the unit from impacts. Support, Updates, and Logging
Zenith Z5 users gain access to technical support for vehicle diagnostics, regular updates, and session logging capabilities (recording communication between the scanner and the vehicle).
Ready for Immediate Use
The scanner is ready for operation immediately upon connection to the vehicle and receipt of onboard power. The software launches in seconds.
J2534 Pass-Thru Support
The device is compatible with OEM (dealer-level) software via the J2534 Pass-Thru protocol.
* Vehicle Connector: The scanner comes standard with a 16-pin cable. Optional cables are available for purchase separately.
Processor: Octa-core 2.0 GHz
Operating System: Android 9
Memory: RAM: 3 GB, ROM: 32 GB
Display: 8 inches, Full HD 1920 x 1200 pixels
Camera: 8 megapixels, autofocus
Supported diagnostic protocols: CAN (High Speed, Low Speed, Single Wire), ISO-9141, ISO-9141-CARB, KWP-2000, SAE J1850 (VPWM, PWM), Melco Pull-Down
Operating voltage: DC 9–30 V
External ports: USB 2.0 x 1, USB 3.0 x 2
Sensors: Built-in: Ambient light, gyroscope, accelerometer
Network: RJ45 Ethernet, Wi-Fi 802.11 a/b/g/n, Bluetooth 4.2
Battery: Lithium-ion 3.8 V, 3200 mAh
Dimensions: 225 x 136 x 33 mm
Technical support is provided by the developer directly.
