For measuring the acceleration performance of cars and any other vehicles. The device is minimalist in style but very functional and can measure all the most sought-after parameters. And, importantly — it is very affordable, 4–5 times cheaper than its analogs! Measurement accuracy is provided by an industrial-grade measurement module from the Swiss company U-box with a data update rate of 10 Hz.
Features
In this version DragON performs the following measurements:
1. Acceleration to a given speed, for example 0-100 km/h.
2. Acceleration time within a range, for example 100-200 km/h.
3. Time and speed over a distance, for example 402 meters (the «quarter», 1/4 mile).
4. Braking to a stop, for example 100-0 km/h.
5. Braking within a range, for example 150-30 km/h.
The maximum timer value for each measurement is 99.9 s. The maximum speed is 360 km/h. The default measurements are 0-100 km/h, 100-200 km/h and 402 meters. The number and type of measurements are fully configurable.
For each measurement the device monitors altitude as well as secondary parameters: the speed at the end of the distance, the distance of a speed measurement, or the braking distance.
Measurement resolution is 0.01 s – hundredths of a second.
DragON 2
DragON 2 is an improved version of popular DragON device, used for speed measurements and data logging in drag-racing. It was born on the streets by two car enthusiasts.
DragON 2 comes with many useful features intended for you to use it out of the box with striking efficiency. It can do almost every measurement found on the dragstrip and is equipped with 10Hz Ublox GPS chip and improved math for industry standard accuracy.
DragON 2 provides acccuracy within 1 tenth of a second and ± 0.1 sec deviation from professional drag equipment in normal conditions. It uses sattelite tracking to pinpoint your location 10 times a second and gives sharp results on any open road, where sky is visible and not obstructed by excessive trees, bridges, wires or harsh meteorological conditions like heavy rain or snow. That is — any normal conditions will do.
DragON 2 can measure the following:
Maximum time measured is 99.9 sec, maximum speed measured — 360 kmph.
The deviced is clocked to 0–100, 100–200 kmph, ¼ mile times out of the box, but you can engage other measurements using any smartphone or even laptop, OS is not relevant. Just connect to «DragON» wifi hotspot, open browser and type 192.168.1.1 — you’re in. See history and fine-tune measurements and use other options we stashed within this device for you. These include sound, screen brightness, etc. You can also see speeds and times with 10 kmph increment — e.g. 0–10 0–20 0–30 or any other increment you like — it’s all in the options to choose, if you feel hardcore.
It can also log data in txt format if equipped with microSD card. Up to 32GB cards are supported.
